Square Flat LED Panel Light

Square Flat LED Panel Light
Square Flat LED Panel Light Square Flat LED Panel Light Square Flat LED Panel Light Square Flat LED Panel Light

Large Image :  Square Flat LED Panel Light

Product Details:
Place of Origin: China
Brand Name: Ground Halo
Certification: TUV, CE, RoHs
Model Number: GH-PLB-6060-45W
Compatible: SAA, UL
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: EXW / FOB / CNF / CIF
Packaging Details: Packing with foam and bubble wrap
Delivery Time: 7 Days
Payment Terms: T/T, PayPal, Western Union,
Supply Ability: 10,000PCS Per Month
Detailed Product Description
High Light:

led panel lights for home

,

led ceiling panels



Square Flat LED Panel Light



Quick Detail:



  1. Product Model: GH-PLB-6060-45W
  2. Luminous Way: Backlit
  3. Certificate: CE, RoHs, TUV, GS
  4. Compatible: SAA, UL
  5. Product Size: 595mm x 595mm x 42mm
  6. Led Brand: Epistar
  7. LED Source: SMD3014
  8. Diffuser: Japanese Import
  9. Lighting Transmittance Efficiency: Up to 93%
  10. Driver: Isolated Constant Current Driver (GS/SAA/CE approval)
  11. Protection Rate: IP50
  12. Color Temperature: Warm White / Nature White / Cold White
  13. Life Span: 50,000Hours
  14. Voltage: AC85V-265V 50/60HZ
  15. Warranty: 3 Years
  16. Wattage: 45W





Description:



GH-PLB-6060-45W Backlit LED Panel Light Fixture with 484 PCS 3014SMD LEDs, produces up to 4,500 lumens, available in Cool White, Natural White, or Warm White. It equip with Japanese Imported High Quality Diffuser, Optical Lens, Aluminum Heat Sink, Italian Design along with Isolated Constant Current LED driver and Taiwanese Super Bright Epistar Chip. We are boast to have plastic frame with outstanding heat dissipation. Designed for residential and commercial conventional suspended grid ceilings for new construction applications or retrofitting existing fluorescent troffer light fixtures. With stable high lumen, 120-degree beam angle, it's typically designed for Commercial Lighting. Moreover, this product is TUV, SAA, CE approved.





5-Years Warranty!  No trouble, No Worry!





More Details:



Backlit, Japanese Imported Diffuser, integrate our engineers’ dedicated development, compose a remarkable LED Panel Lighting fixture.



Benefit from White polish plastic frame, this Backlit LED Panel Light still is easy to be suspended although it’s backlit (thickness: 42mm). Moreover, the whole panel is looked more upmarket.



Elegant and Elaborately design. Every detail is in result of our engineers' delicate workmanship and continuing efforts.



The luminous flux has been dramatically improved, compare to side lit LED Panel Light. It’s great to apply as commercial Lighting, and those other places need bright light.







Specification:



A: Technical Parameter

Item  No.

GH-PLB-6060-45W

Dimension

595x595x42mm

Voltage

AC85V-265V  50/ 60HZ

Power

45W

LED  Type

SMD3014

LED  Quantity

484pcs



Luminous Flux

Warm  white

> 3825 lm

Neutral  white

> 4050 lm

Pure White

> 4275lm



Color  Temperature

(CCT)

Warm  white

2800-3500K

Neutral  white

3800-4500K

Pure White

5500- 6500K

Beam Angle

120°

Color  Rendering  Index  (CRI)

Ra 80

Power  Supply  Efficiency

>90%

LED  Luminous  Efficiency

Up  to  110 lm/W

Power  Factor  (PF)

>0.95

Total Harmonic Distortion  (THD)

≤15%

IP Rank

IP  50

Net weight

2.5kgs

Certificate

TUV/CE/RoHS



B: Mechanical Specifications

LED Driver

Isolated Constant Current LED Driver

Connection  to  Power

2X1.0mm 2PVC Cable

Housing  Processing

White  Paint  Coating

Material

PMMA, Plastic  housing

Cover

Frosty  Front Cover



Installation  Component Set

1. Recessed Installation, YES

2.Suspend Installation, Optional



C: Environmental

Temperature  Range  Operating

-20℃ to 40℃

Humidity  Range  Operating

20 % to 95 %

Temperature  Range Storage

-40℃ to 75℃

Humidity  Range Storage

10 % to  80 %





Dimension:



Square Flat LED Panel Light 0





Light Distribution Curve & Max CD Distribution Curve:



Square Flat LED Panel Light 1





Illumination  Diameter:



Square Flat LED Panel Light 2





Electrical Connection:

Square Flat LED Panel Light 3





Installation:



Warning: Before installation, please make sure the power is turned off.



A. The standard False Ceiling Installation

Square Flat LED Panel Light 4

Step1:Opening the false ceiling





Square Flat LED Panel Light 5



Step2:Install the panel light








Square Flat LED Panel Light 6

Step3:Connect the wire for panel










B . The embedded installation

Square Flat LED Panel Light 7

Step1.To Saw a hole according the panel holing demension





Square Flat LED Panel Light 8



Step2.Install the panel in the hole of ceiling








Square Flat LED Panel Light 9

B . The embedded installation










C.The suspended installation

Square Flat LED Panel Light 10

1.To drill the holes on the Ceiling,Fix the components with screws on the Ceiling.

Square Flat LED Panel Light 11

2.To fix the steel rope at the panel suspended  components








Square Flat LED Panel Light 12

3.To adjust the panel height.

Square Flat LED Panel Light 13

C.The suspended installation












Packing Information:



Material

QTY/ CTN

Carton  Size

G.W.

Carton

1pcs

680*640*110mm

3.28kgs





Packing Details:



Square Flat LED Panel Light 14





Drop and Impact Test:



  1. Each edge (as chart below) has been  tested.
  2. The appearance and Performance of the LED Panel Light  has  been rechecked  after the Test.



Square Flat LED Panel Light 15





Warranty:



3-year warranty since the date of purchase is offered for all Backlit Panel Light.





Term of Warranty:



  • Under terms of this warranty, if the product has a failure occurring under normal usage within   warranty period, Ground Halo will provide free maintenance service based on the proof- documents and invoice (copy) of failure product.
  • Ground Halo will not provide paid maintenance service by under conditions within warranty.
    • Failure or damage due to force majeure.
    • Failure or damage due to transport or unloading.
    • Failure or damage due to incorrectly usage or fail to comply with the User's Guide and Caution.
    • Failure or damage due to demolition, repair, alteration without Manufacturer's authorization.
  • Please  deliver  the failure product by original packing for maintenance service, Ground Halo will  not be responsible for any failure or damage in transportation if customer uses non-original packing or improper packing.



Ground Halo reserves the right for final explanation of aforesaid terms.

Caution : Ground Halo will not be responsible for any other failure or damage by incorrectly usage.





Application:



Shopping Mall, Supermarket, Office, School, Library, Bathroom, Kitchen, Department Store, Restaurant, Cafeteria, Hospital, Laboratory, and Conference Room etc.



Square Flat LED Panel Light 16

Square Flat LED Panel Light 17





Square Flat LED Panel Light 18











Term of Trade:



1. Payment: T/T 30% deposit, 70% before shipment ,L/C ,western union or paypal.
2. Lead time : Within 7-20 working days after receiving the deposit
3. Samples: Can be ready in 5 working days once payment received
4. Shipping port: Shenzhen, China
5. Discounts : We offer discount for large quantity
6. Packaging: Neutral package, also can be customized according to customer requirements of Logo, Brand etc.





Why Choose Us?



  • Your inquiry related to our products or prices will be replied whitin 24 hour
s.
  • Experienced sales to answer all your inquiry in short time.

  • Clients' special requirement is accepted. We also provide Lighting Solution and recommend the best suitable lights to you.

  • Protect your sales area, ideas of design and all your private information.
