Lamp Power(W): | 20W | Floodlight Type: | PIR Motion Sensor Function |
---|---|---|---|
Voltage: | 85V-265V AC | Detection Distance(Adjustable): | 4 ~12m (<24) |
Time Delay(Adjustable ): | 10 Sec To 7min(+/- 5%) | Light Control( Adjustable): | 3-3000LUX |
High Light: | external led flood lights,outdoor led floodlight |
► Function Switches
SENSE: Adjust the sensitivity of the PIR Sensor motion sensor
TIME: Ajdust the time the floodlight will stay on(e.g. from 5secs to 8 minutes)
LUX: Adjust the emvironment lux/ brightness the sensor will start function(e.g adjust to "SUN " symbol, the sensor will function at both day time and night time, adjust to"MOON' symbol, the sensor will only work at night time)
OVER-RIDE FUNCTION: when switch the power on-off-on quickly, the floodlight will stay on until you switch off for few secs, and switch on again, it will return to PIR model. ONE PIR floodlight have both normal illumination and security floodlight function!!
► Specification
Input voltage |
AC85V-265V |
||
Frequency |
50HZ-60HZ |
||
Total harmonic distortion |
≤9% |
||
Power factor |
> 0.98 |
||
Voltage for the led |
DC30-36V |
||
LED QTY |
1PC |
||
Total power of the led |
20W |
||
Total power for the light |
23W |
||
LED light effect |
90-100LM/W |
||
Initial lumens |
Pure white 1920LM |
||
Cool white 1872LM |
|||
Warm white 1700LM |
|||
Light efficiency |
Above 90% |
||
Average illumination |
Height:2M |
26 LUX |
|
Height:3M |
11.5LUX |
||
Height:4M |
6.5LUX |
||
Light spot |
Height:2M |
3.3*3.3M rectangle |
|
Height:3M |
6.5*6.5M rectangle |
||
Height:4M |
9.8*9.8M rectangle |
||
Evenness degree |
>0.7 |
||
Related color temperature |
WW |
2700K-3900K |
|
PW |
3900K-6000K |
||
CW |
6000K-7000K |
||
Color rendering |
WW |
Ra>78 |
|
|
PW/CW |
Ra>85 |
|
Light distribution curve |
Symmetric expression/rectangle light spot |
||
Light design |
LED+ reflector secondary light distribution |
||
Warming node of the led |
≤70℃ |
||
Operation temperature |
-30℃~+55℃ |
||
Storage temperature |
-25℃~+65℃ |
||
Grade of protection |
IP65 |
||
Life-span of the led |
>50000H |
||
Connecting wire for the driver |
Brown |
“L” live line |
|
Blue |
“N” neutral line |
||
Yellow/ Yellow-green |
“G” earth line |
||
Color of housing |
Black/ Gray |
||
Certificates |
CE & ROHS |
||
NW. / GW. |
2.4Kg/2.6Kg |
||
Package size |
27.5*16.5*23.5 (cm) |
► Application
PIR Motion Sersor LED Flood Light is widely used in billboard lighting, family courtyard, corridor, shopping malls, sports venues, supermarkets, schools, hospitals, roads, building facade lighting, landscaping, lighting bar, ballroom, places of entertainment, hotels, villas, home decorative lighting, etc., due to its high color rendering, can also be used for jewelry appraisal, printing and dyeing, clothing, medical lighting, national defense work, scientific experiments, photography lighting, etc. It is the ideal choice to now replace the traditional halogen lamps.
