| Power: | ZLONE | Model: | ZL-TGD-100W |
|---|---|---|---|
| Wattage: | 100watt | LED Brand: | Bridgelux Chip 45mil |
| IP Rating: | 1p66 Ip65 | Input Voltage: | 90-260vac 50-60Hz |
| High Light: | external led flood lights,dimmable outdoor led flood lights |
||
100W LED Flood light Bridgelux chip 45mil 10000lm 120° angle IP66 Rating 3 Years Warranty CRI80
-------------------------------------PRODUCT Feature ---------------------------------------
1. Led chip: High lumen EPISTAR chip-on-board chips or BRIDGELUX delivery 80lm/w high lumens in high CRI for lighting performance and have 120o beam angle for lighting.
2. Lifespan: ZLONE’s led flood light has 50000 hours lifespan for using. You can using 5 years base on using 10 hours per day.
3. Led Power Supply: Constant current Mean well series power supply will protect LED chip in correct current and voltage. It provide power factor >0.9 and power efficient > 90% characteristic to ensure power saving. Also it has over current, over voltage, over temperature and short circuit protection to ensure the long time lifespan.
4. Lamp Housing: High quality aluminum alloy housing with spray painting surface finish, dust-resistant, moisture-proof, firm and durable. The lead time of manufacture is fast because of die-casting production process. Also the quality of the lamp housing is same.
5. Glass Cover: High quality 4mm-5mm thickness heat-resistant temper glass will not splash when the flood light is exploded in wrong operation. It guarantees 100% light transmittance and uniform light distribution.
6. Heat sink: Sufficient and thickness liner radiation fin are average distributed on the back of front head by die-casting technology with excellent thermal conductivity.
7. IP65 waterproof structure:Every gap, screw and interface used the rubber ring with silica gel for waterproof purpose.
8. Adjustable bracket: It can adjust 0-180o beam angle in horizontal direction for different application purpose.
9. Warranty: ZLONE offers 2-years product warranty for all products. If you need 5-years warranty for this wattage product, please contact us directly.
Customized your LED flood light:
1. Different led chip brand:Epistar/Bridgelux/CREE
2. Dimmable are available,compatible most dimmer,RF remote prepared
3. Isolated power supplier and non-isolated power could be chosen.
4. Regular lumen 90-100lm/w,Highest lumen 130lm/w or 120-140lm/w for chosen.
5. Different power supplier solution:lowest temperature upto -40 degree.it could be updated to Meanwell power supplier.
6. Long life span,20000/50000 hours,2-5 years warranty by your request.
Specifications:
Part No. | ZL-TGD-100W | |
Optics Parameters
| Light Source | 1pc bridgelux chip 45mil |
Luminous Flux(lm) | 9800LM | |
CCT(K) | warmwhtie(3000K)/white(6000K)/ Neturalwhite4000K | |
CRI(Ra) | more than 80Ra | |
Beam Angle | 120 degree | |
Light Attenuation ratio (%) | less than 3% in 30,000Hrs | |
Lifespan (Hrs) | more than 50,000Hrs | |
Electric Parameters | Input Voltage(V) | 85-265Vac |
Frequency(Hz) | 50/60 Hz | |
Input Current(mA) | 86mA (@ 220 Vac ) | |
Total Power(W) | 105W | |
Power Factor | 0.95 | |
Turn-on Time(S) | less than 0.05 S (@ 220Vac) | |
Dielectric Voltage Withstand Test | 3750Vac/1min | |
Structure Parameters | Material | Aluminum+ PMMA |
Size(mm) | 380*280mm | |
Net Weight(g) | 7.35KG | |
Water Proof(IP) | IP66 | |
Integrated Parameters | Operating Temperature | -40 ~ +55 Centigrade |
Storage Humidity | 0% ~ 95%R.H. | |
Dimmable | Optional | |
instructions: | |
1.LED is DC driven, low power consumption device.It is anti-seismic, impact resistant,Non-thermal | |
radiation,secure stable,reliableWorry free for thermal dissipation, long lifespan, compact | |
light body ,simple installation chic style, manufacturing excellence and product serration. | |
2.Energy saving,environment-friendly,waste free,completely recyclable. | |
