Product Details:
Payment & Shipping Terms:
|
| High Light: | led t8 tube lights,led tube light fixtures |
||
|---|---|---|---|
1.Auto switch on/off
2.Light sense function: auto identify the environment illuminance,and working after it.
3.energy saving
4 Special circuit design, each LED work separately
Applications:
a)Direct replacement of T8/T10 fluorescent tube.
b) Note: It is used in some fixed places including path ,porch, bathe room, washroom, kitchen, veranda, stair well and park etc.
Specifications:
|
PRODUCT SPECIFICATIONS |
|||
|
Product name |
20W 4feet LED TUBE LIGHT |
||
|
Part NO |
GLTL-T8A-L12-W20W |
GLTL-T8A-L12-W20N |
GLTL-T8A-L12-W20C |
|
Bulb Type |
T8 |
||
|
Base Type |
G13 |
||
|
Dimension |
26X1204 mm |
||
|
Net Weight |
390g |
||
|
Technical Characteristic |
|||
|
Color |
warm white |
natural white |
cool white |
|
Coior temperature |
2700-3500K |
3700-4500K |
5500-7000K |
|
CRI |
70-80 |
70-80 |
70-80 |
|
Lumen |
1720LM |
1920LM |
1920LM |
|
Illuminance@1m |
270lux |
300lux |
300lux |
|
Lumen Efficacy |
86 lm/w |
96 lm/w |
96 lm/w |
|
Input Power |
20W |
||
|
Viewing Angle |
120 Degree |
||
|
Dimmable Type |
DALI , TRIAC |
||
|
Input Voltage |
90-265VAC |
||
|
Frequency Range |
47~62HZ |
||
|
PFC |
＞90% |
||
|
Life Span |
40000 Hours |
||
|
Equivalent |
36W Fluorescent lamp |
||
|
Waterproof Rating |
IP20 |
||
|
MATERIALS |
|||
|
LED Brand |
EPISTAR |
||
|
LED Type |
3528 SMD LED |
||
|
LED QTY |
288 Pcs |
||
|
Housing |
Aluminum |
||
|
Housing Color |
Sliver |
||
|
Lens |
PC |
||
|
OTHERS |
|||
|
Operating Temperature |
-20℃ TO 45 ℃ |
||
|
Operating Humidity |
20%-90% RH |
||
|
Storage Temperature |
-30℃ TO 80 ℃ |
||
|
Storage Humidity |
10%-95% RH |
||
|
Application |
Indoor |
||
|
Enviroment Protection |
RoHS |
||
|
Safety Certification |
CE FCC |
||
|
Warranty Time |
2 Years |
||
|
PACKING |
|||
|
Size of box |
L1225 X W35 X H35 mm |
||
|
Gross Weight |
500g |
||
|
Packing |
1320 x 310x200mm /40pcs/22Kg |
||
|
20 GP |
240 Carton/9600 pcs /5280Kg |
||
|
40 GP |
480 Carton/19200pcs /10560Kg |
||
