Product Details:
Payment & Shipping Terms:
|
Power: | 12W | Size: | 300*300*9.8mm |
---|---|---|---|
Item Type: | Panel Lights | Square: | Ultra Thin Led Light Panel |
Working Lifetime(Hour): | 50000 | Feature: | Ultra Thin |
High Light: | led flat panel ceiling lights,flush mount led ceiling light |
12W CE RoHS FCC Approval Ultra Thin Flush Mount LED Ceiling Light For Photo Studios
Description:
* Aluminum with high quality laser dotted guide panel light
* Super size accept customized
* CRI>80
* Beam angle is 125°
* Up to 80% energy saving
* Instant star, no flicking, no humming
* No RF interference
* Environmentally friendly, mercury and lead free
Applications:
1.Meeting room, conference room,communication office
2.office, gallery and home
3.Commercial environment, real estate, commercial building,Airport
4.Shopping mall, super market,chain shops, shops, hotel, restaurant
Specifications:
Dimension |
300*300*9.8mm |
Wattage |
12W |
Luminous Flux |
>3200LM |
LED Source |
120pcs SMD 2835 Epistar |
Input Voltage |
AC95-240V, 50/60HZ |
Housing |
PMMA+Aluminum |
CCT |
WW2700-3200K, NW4000-4500K,CW 6000-6500K |
CRI |
>80Ra |
Dimming Type |
PWM Dimming |
Frame |
Unprocessed virgin aluminum/White coating aluminum |
Operating Temp. & Humidity |
-10 ~ +65 cesius, 10~80% |
Storage Temp. & Humidity |
-40 ~ +85 cesius, 10~80% |
IP Rating |
IP42 |
Beam Angle |
120° |
Installation |
Suspended/Mounted/Recessed |
Gross Weight |
5g/pc |
Package |
1pc/box , 5pcs/carton |
Carton Size |
645x645x60mm |
Expected life span |
50,000 Hrs |
Certification |
CE, RoHS
|
Part No | Input Voltage | Power | Dimension | CRI | Luminous Flux | |||
@3000K | @4000K | @5000K | @6000K | |||||
EB-GL600*300-XX22-C | 90-264VAC | 12W | 300*300mm | CRI>80 | 1804lm | 1914lm | 1890lm | 2046lm |
EB-GL600*600-XX32-C | 32W | 595*595mm | 2624lm | 2784lm | 2880lm | 2976lm | ||
YRH-GL600*600-XX42-C | 42W | 595*595mm | 3444lm | 3654lm | 3780lm | 3906lm | ||
YRH-GL620*620-XX32-C | 32W | 620*620mm | 2624lm | 2784lm | 2880lm | 2976lm | ||
YRH-GL620*620-XX42-C | 42W | 620*620mm | 3444lm | 3654lm | 3780lm | 3906lm | ||
EB-GL1200*300-XX32-C | 32W | 1195*295mm | 2624lm | 2784lm | 2880lm | 2976lm | ||
YRH-GL1200*300-XX42-C | 42W | 1195*295mm | 3444lm | 3654lm | 3780lm | 3906lm | ||
YRH-GL1200*600-XX60-C | 60W | 1195*595mm | 4920lm | 5220lm | 5400lm | 5880lm | ||
YRH-GL1200*600-XX83-C | 83W | 1195*595mm | 6806lm | 7221lm | 7470lm | 7719lm |
Applications for led panel light price:
A) Edge-lighting of transparent or diffused materials; Path & Contour Marking.
B) To couple light into transparent or diffused glass; Widespread use in
accessorial lights for indoors.
C) Architectural lighting, villa, restaurant, hotel, meeting room, show room,
shop, counter and so on.
D) General lighting, Task lighting, household appliances.
Architectural lighting, Decorative / pathway lighting.
